High Temperature Boron Carbide Sandblasting Nozzle with 600°C Max Operating Temperature and Thermal Shock Resistant 30x6mm Straight Bore
Detalhes do produto:
| Lugar de origem: | Hunan, China |
| Marca: | High Broad |
| Certificação: | ISO 9001:2015 |
| Número do modelo: | HB-B4C |
| Documento: | Venturi nozzle Jane.pdf |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 10 peças |
|---|---|
| Preço: | USD 9.00 - 22.00 / Piece |
| Detalhes da embalagem: | Caixa individual forrada com espuma, papelão ondulado de qualidade para exportação com barreira cont |
| Tempo de entrega: | 3-5 dias úteis para estoque, 15-20 dias para produção |
| Termos de pagamento: | T/T, L/C, PayPal, Western Union |
| Habilidade da fonte: | 50.000 peças por mês |
|
Informação detalhada |
|||
| Densidade: | ≥2,48g/cm³ | Temperatura operacional máxima: | 600°C |
|---|---|---|---|
| Comprimento do bico: | 30mm | Pressão operacional máxima: | 0,8 MPa (116 PSI) |
| Tópico de conexão: | M12x1.5 | Resistência ao choque térmico: | Excelente (ΔT ≥ 400°C) |
| Destacar: | High Temperature Nozzle,Thermal Shock Resistant Sandblast,Heavy Duty Blasting Nozzle |
||
Descrição de produto
Key Advantages
High Temperature Endurance
Maintains full mechanical strength and wear resistance at continuous operating temperatures up to 600°C. No softening, deformation, or performance degradation in hot blasting environments.
Thermal Shock Proof
Withstands rapid temperature changes exceeding ΔT 400°C without cracking or spalling. Safe for intermittent hot-surface blasting where thermal cycling is unavoidable.
Focused Straight Bore
30mm straight bore with 6mm diameter concentrates abrasive energy into a tight, high-impact stream. Ideal for spot blasting, weld cleaning, and precision rust removal on hot surfaces.
Heavy Duty Construction
Thick-walled B4C ceramic body withstands high-pressure blasting at 0.8 MPa. Designed for the toughest foundry, shipyard, and steel mill environments.
Technical Specifications
| Material | Boron Carbide (B4C) Ceramic |
| Nozzle Type | Straight Bore |
| Bore Diameter | 6mm |
| Nozzle Length | 30mm |
| Max Temperature | 600°C |
| Thermal Shock ΔT | ≥400°C |
| Hardness | ≥2800 HK (Knoop) |
| Max Operating Pressure | 0.8 MPa (116 PSI) |
Applications
- Foundry casting cleaning and descaling at elevated temperatures
- Hot forging scale removal and surface preparation
- Steel mill roll and equipment maintenance blasting
- Heat exchanger tube and boiler cleaning
- Weld seam cleaning on preheated heavy steel structures
