Multi Cable Option HMWPE XLPE Kynar MMO Linear Anode Selectable Insulation for Soil Chemistry Matching
Detalhes do produto:
| Lugar de origem: | China |
| Marca: | High Broad or OEM |
| Certificação: | ISO 9001, ASTM B348 |
| Número do modelo: | MMO-CS-008 |
|
Informação detalhada |
|||
| Tipo de ânodo: | Ânodo linear MMO selecionável por cabo | Opções de cabo: | HMWPE / XLPE-PVC / Kynar-HMWPE |
|---|---|---|---|
| Suporte à seleção: | Revisão Gratuita de Análise de Solo | Classificação HMWPE: | pH 5-9, < 75°C |
| Classificação XLPE/PVC: | pH 3-12, <90°C | Classificação Kynar/HMWPE: | pH 2-14, resistente a produtos químicos |
| Destacar: | Anodo linear MMO de múltiplos fios,HMWPE XLPE Kynar CP Cable,Anodo de isolamento compatível com o solo |
||
Descrição de produto
Cable-Selectable MMO Linear Anode System
One anode design does not fit all soil conditions. Our cable-selectable MMO linear anode system allows engineers to match cable insulation to site-specific soil chemistry, maximizing system life and reliability without over-specifying.
Cable Selection Guide
| Insulation | Best For | Limitations |
|---|---|---|
| HMWPE | Standard buried service, neutral to mildly acidic soils (pH 5-9), general moisture resistance | Not recommended for organic solvent exposure or temperatures above 75°C |
| XLPE/PVC | Higher temperature soils (up to 90°C), wet environments, good chemical resistance | PVC outer layer may degrade in highly alkaline soils (pH > 12) |
| Kynar/HMWPE | Aggressive chemical environments, acidic soils (pH 2-5), refinery and chemical plant sites | Higher cost; specify only when required by soil chemistry |
Selection Support
We provide complimentary soil analysis review — send your site soil resistivity and chemistry data, and our engineering team recommends the optimal cable configuration. No charge, no obligation.
The anode core (MMO/Ti wire, coke backfill, splice connections) remains identical across all cable options, ensuring consistent CP performance regardless of cable selection.
Applications
- Projects with variable soil conditions along route
- Sites requiring cost-optimized cable specification
- Retrofit projects with known soil chemistry history
